Skyfold – Zenith

Skyfold is a vertical movable wall system that retracts to the ceiling. It is space-saving, requires no guide or track rails and offers acoustic insulation up to Rw 59 dB. Zenith combines the vertically folding elements found in the Classic Series at the top portion of the wall with a straight down descent thereafter, making it the ideal flexible space solution for areas that require a narrow path of travel..

Categories: ,

Description

Product Details

Surface Finishes

  • Wood veneer
  • Fabric
  • Metal
  • Vinyl
  • Plastic laminate (melamine)
  • Painted
  • Write-on surfaces/whiteboard
  • Custom design
    *Zenith 48 is limited to standard fabric, standard vinyl, and markerboard finish

Technical Data

  • Clear passage height: up to 3,660 mm
  • Element width: unlimited (Zenith 48 restricted to 14,600mm long)
  • Element depth / acoustic insulation:
Rw in dB RW47
(STC 48)		 RW51
(STC 51)		 RW54
(STC 55)		 RW59
(STC 60)		 RW49
(STC 50 & NRC up to 0.65)
Weight kg/m2 29.3 kg/m2 30.4 kg/m2 33.3 kg/m2 42 kg/m2 32.8 kg/m2
Features:
  • Retracts into the Ceiling to Maximize Floor Space
  • Narrow Path of Travel
  • No Floor, Wall Tracks or Visible Hinges
  • Fully Automatic
  • Easy-to-Use Operation with LCD Display Touch Screens
  • Equipped with a Safety Obstruction Sensor

Downloads

Skyfold Zenith Brochure
DIMENSIONS FOR STANDARD DRIVE SYSTEM
